8V 25A DC Electroplating PCB Rectifier Power Supply Low Ripple High Frequency
  • 8V 25A DC Electroplating PCB Rectifier Power Supply Low Ripple High Frequency
  • 8V 25A DC Electroplating PCB Rectifier Power Supply Low Ripple High Frequency
  • 8V 25A DC Electroplating PCB Rectifier Power Supply Low Ripple High Frequency
  • 8V 25A DC Electroplating PCB Rectifier Power Supply Low Ripple High Frequency

8V 25A DC Electroplating PCB Rectifier Power Supply Low Ripple High Frequency

Place of Origin China
Brand Name Xingtongli
Certification CE
Model Number GKD(M)(H)8-25CVC
Product Details
Application:
Electroplating
Efficiency:
>85%
Control Way:
Panel Control
Cooling Way:
Air Cooling
Color:
Black
Type:
AC To DC
Highlight:

copper plating rectifier

,

pcb electroplating power supply

Payment & Shipping Terms
Minimum Order Quantity
1 SET
Price
Negotiable
Packaging Details
Wooden case
Delivery Time
5~7 working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability
100 SET/month
Product Description

8V 25A small black pure dc low ripple electroplating rectifier



8V 25A small black pure dc low ripple electroplating rectifier is used to electroplating. This rectifier adopted our newest technology. It's pure dc and will not add any extra fees from customer. Smaller and lighter.



Ampere-min meter is extra parts. It has doing and cumulative time functions.



Some pics was followed

8V 25A DC Electroplating PCB Rectifier Power Supply Low Ripple High Frequency 0

Back

8V 25A DC Electroplating PCB Rectifier Power Supply Low Ripple High Frequency 1



Application

Different volt and current has different applications

8V 25A DC Electroplating PCB Rectifier Power Supply Low Ripple High Frequency 2



Specification

SPECIFICATIONS FOR GKD(M)(H)8-25CVC
Input AC 110V±10% 1phase 50/60Hz
Output DC Volt 0~8V            Adjustable
Current 0~25A         Adjustable
Power 0.2KW
Efficiency >85%
Ripple <5%
Switching Frequency 20KHz
Protection Short circuit protection
Overheating protection
Phase lack protection
Input over/low voltage protection
Working Condition
(Temperature)
-10℃~50℃ Control mode Panel control
Remote control
Net weight 7.5kg Working mode Constant Voltage(CV)
Constant Current(CC)
Dimension(mm) 273*222.5*88 Cooling way Air cooling

Features
electroplating rectifier.jpg


1. 0~10V, 4~20mA,PLC,Timer, Ampere-minute/hour counter, HMI can be provided


2. Control mode: Local control or Remote control(the length of cable is determined by customers)


3. Japan IGBT(the default choice) or Germany IGBT are adopted


4. After being phosphated, galvanized and plastic sprayed, the chassis has excellent corrosion resistence function


5. Easy to operate and repaire



Other advantages

8V 25A DC Electroplating PCB Rectifier Power Supply Low Ripple High Frequency 4



1. Cabinet
a: Adopting completely digitalized machining
b: Adopting cold rolled production of iron steel sheet, after phosphorization, zinc plating, plastic spray, the rectifier gets better structural strength and anti-corrosion.
c: Reasonable structure design, isolated inverter design, rectification part is convenient to disassemble and mend because of its neat assembling.
d: Radiator gets better cooling effect because of its 1.5 times capacity.



2 Electric control system
a: The rectifier adopts full bridge phase-shifted soft switch control, ensuring the lowest power loss of IGBT. The capacity of IGBT become 3 times bigger.
b: The main transformer. It adopts amorphous core to increase transformer efficiency and cool transformer, and not only can lighten rectifier weight, but also can strengthen rectifier stability and reliability. At its elementary stage, it adopts series blocking capacitor.
c: Magnetic deviation automatic correction circuit is adopted and the total power of magnetic core gets enlarged 1.5 times.



3 Schottky Barrier Diode
a: It has been expanded 4 times.



4 All the controlling boards get antiseptic treatment with imported lacquer.



How to install rectifier
This is installation way for remote control rectifier. Not only this way.
1. To connect copper bar with bath/tank
2. To ensure power supply/rectifier is grounded
3. To ensure there is enough water for water cooling type power supply/rectifier
4. We advice that all rectifiers should be isolated to increase of its life.

8V 25A DC Electroplating PCB Rectifier Power Supply Low Ripple High Frequency 5

8V 25A DC Electroplating PCB Rectifier Power Supply Low Ripple High Frequency 6



Our service



Pre sale service
1. To answer your questions within 24hours.
2. 3D design picture and wiring diagram can be offered.
3. Inner part pictures can be offered
4. OEM and ODM is accepted

After sale service
1. To resolve your problems within 24hours.
2. Replacement parts can be offered for free within 1 year warranty
3. The machine is damaged by quality and can be changed for free within 1 year
4. The client can check the rectifier before the factory by themselves or test video can be offered
