Electrolysis Power Supply

HF Switching Electroplating Rectifier SMR 12v 400a With 380v 3 Phase AC Input

All Category

Electrocoagulation Power Supply

High Frequency Switching Power Supply

HF Switching Electroplating Rectifier SMR 12v 400a With 380v 3 Phase AC Input

Brand Name:	xingtongli
Model Number:	GKD12-400CVC
MOQ:	1 unit
Price:	1070$~1200$
Packaging Details:	Single wooden case packing size:690550520mm Weight:70kg
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO CE RoHS

Product Name:

HF Switching Rectifier SMR 12v 400a With 380v 3 Phase AC Input

Input Voltage:

AC 380V/220V/415V/480V

Phase:

3 Phase

Output Voltage:

DC 0~12v Adjustable

Output Current:

DC 0~400A Adjustable

Work Mode:

CC CV

Size:

520*395*165mm

Weight:

Color:

White

Supply Ability:

150units/month

Highlight:

electrolytic rectifier

electrolysis machine power supply

HF Switching Electroplating Rectifier

Product Description

HF switching Rectifier SMR 12v 400a with 380v 3 phase AC input Specification and parameter

Description of high frequency electrolytic power:

switching Rectifier SMR main circuit includes main transformer, power rectifier components and some other testing, protection devices. Power supply main transformer function is to reducing AC current/voltage to the plating technical process required voltage value. Thyristor rectifier uses frequency (50Hz/60Hz) transformer, while high-frequency switching power supplies using high frequency (10 ~ 50kHz) transformer. Detection devices include voltage meter, current transformers. Protection device is mainly used for power rectification components over-current protection. The control circuit includes a thyristor or IGBT, trigger control circuit, power soft-start circuit, over-current, over-voltage protection circuit, power phase protection circuit.

input voltage	380v 3 phase 50/60hz
Output voltage	0~12v adjustable
Voltage stability	0~400a adjustable
Current stability	≤1%
Ripple factor	1%-2%
efficiency	≥90%
weight	25kg
dimension	520395165mm
Stabilization mode	Current stabilization/Voltage stabilization (Switchable easily)
Adjustment range	Voltage/Current from 0-100% continuously adjustable within rated range
Cooling system	Air cooling
Control method	local control/remote control/plc control
Display contents	Voltage meter/Current meter/Working/Over temp/Error,
Protection method	Input over-voltage/Under-voltage/Over current/Output short/Over heating self protection etc..
Operating temperature	-20-50℃
Ambient temperature	-30-65℃
Ambient humidity	≤90%

HF Switching Electroplating Rectifier SMR 12v 400a With 380v 3 Phase AC Input 0

HF Switching Electroplating Rectifier SMR 12v 400a With 380v 3 Phase AC Input 1

Cabinet:

HF switching Rectifier SMR with timer adopts magnetic cut links, reduce eddy current losses, and cabinet as a whole spray painting

Structure:

HF switching Rectifier SMR with timer with reasonable structure design, isolated the inverter part and , rectification part , convenient to disassemble and maintenance

Radiator:

radiator capacity expanded 1.5 times,make sure better cooling effect

switch control way:

adopt full bridge phase shifting soft switch,reduct IGBT loss,save engergy

Main transformer:

60v 125A Switch Mode IGBT TR rectifier for electrochilorination system adopts amorphous core,increase transformer efficiency,reduct the transformer temperature rise,cut the rectifier weight,improve the power supply stability, reliability

Core & Schottky diode:

core capacity expanded 1.5 times

schottky diode expands 4 times

Board :

all control boards did anticorrosion treatment with imported three defense lacquer

IGBT:

IGBT capacity expanded 3 times,make the power supply more reliable

Application ofHF switching Rectifier SMR :

Mainly used in non-ferrous metal electrolysis: aluminum, magnesium, zinc, lead, copper, manganese and manganese dioxide; gold, silver and other metals smelting; neodymium iron boron rare earth smelting; hard alloy, diamond smelting; salt water, potassium electrolysis to produce caustic soda, potash, sodium system; fire electrical heating materials, and other types of high-power DC power supply.

HF Switching Electroplating Rectifier SMR 12v 400a With 380v 3 Phase AC Input 2

HF Switching Electroplating Rectifier SMR 12v 400a With 380v 3 Phase AC Input 3

1, Placing rectifier and keep the body stability; ensure good ventilation.

2, Checking anodizing rectifier out cover if loosing.

3, Connecting shell to ground to prevent static electricity.

4, Conecting the AC input wire

5, Connecting the DC output copper bars

6, Connecting the rectifier remote control box,if local control ,skip this step

7, Turn on air switch, then the fan starts to rotate and the power indicator light.

8, Clockwise rotation adjustment button, voltmeter degree increases, working indicate light lighting.

9, Adjust knob to maximum, then the voltmeter should indicate the rated voltage, current meter indicates the load volume accordingly.

10, Disconnect the air switch, turn off the rectifier
