12V 2000A 24KW IGBT Electroplating Rectifier High-Power For Nickel / Copper / Silver / Gold Plating Industrial-Grade Durability
  • name
  • name
  • name
  • name
  • name

12V 2000A 24KW IGBT Electroplating Rectifier High-Power For Nickel / Copper / Silver / Gold Plating Industrial-Grade Durability

Brand Name: Xingtongli
Model Number: GKD12-2000CVC
MOQ: 1pcs
Price: 1200-2000$/unit
Packaging Details: strong plywood standard exporting package
Payment Terms: L/C,D/A,D/P,T/T,Western Union,
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE ISO9001
Supply Ability:
200 Set/Sets per Month
Highlight:

24KW Electroplating Rectifier

,

Industrial Grade Electroplating Rectifier

,

12V Electroplating Rectifier

Product Description

Product Description

The 12V 2000A 440V 3-Phase IGBT Electroplating Rectifier is specially designed for nickel, copper, silver, gold, and other metal plating applications, offering industrial-grade durability and precision for high-accuracy surface treatment. Utilizing IGBT (Insulated Gate Bipolar Transistor) technology and a nanocrystalline soft magnetic material transformer, it delivers efficient and stable DC output. The rectifier supports a 3-phase 440V input, with a continuously adjustable output voltage of 0-12V and a sustained 2000A current load. Boasting an impressive 89% efficiency, it significantly reduces energy consumption.

Product Parameters

Input Specifications

  • Voltage: 3-Phase AC 440V
  • Frequency: 50/60Hz

Output Specifications

  • Voltage Range: 0-12V continuously adjustable (digital display, adjustment accuracy ≤1%)
  • Current Range: 0-2000A continuous output (constant current/constant voltage dual-mode switching)
  • Output Ripple: ≤1% (high-frequency PWM modulation technology)
  • Efficiency: ≥89% (IGBT topology with nanocrystalline transformer)

Protection Functions

  • Overcurrent Protection
  • Overheat Protection
  • Overvoltage/Undervoltage Protection
  • Short Circuit Protection

Certifications and Compliance

  • Safety Certifications: CE certified (compliant with LVD, EMC, and RoHS directives)
  • Industry Standards: Meets IEC 60950-1 (Safety of Information Technology Equipment) and ISO 9001 quality management system

Typical Application Scenarios

  • Metal Plating: Single-metal and alloy coatings (nickel, copper, silver, gold) for electronic components, jewelry, and automotive parts.
  • Surface Treatment: Anodizing, electropolishing, electroforming, and other processes requiring high current density.
  • Industrial Production: Large-scale plating lines requiring long-term stable power supply, such as PCB manufacturing and bathroom hardware processing.12V 2000A 24KW IGBT Electroplating Rectifier High-Power For Nickel / Copper / Silver / Gold Plating Industrial-Grade Durability12V 2000A 24KW IGBT Electroplating Rectifier High-Power For Nickel / Copper / Silver / Gold Plating Industrial-Grade Durability12V 2000A 24KW IGBT Electroplating Rectifier High-Power For Nickel / Copper / Silver / Gold Plating Industrial-Grade Durability
