12V 1000A 12KW IGBT Power Supply High Frequency DC Power Supply Alloy Sliver Copper Gold Plating Rectifier

All Category

Electrocoagulation Power Supply

High Frequency Switching Power Supply

12V 1000A 12KW IGBT Power Supply High Frequency DC Power Supply Alloy Sliver Copper Gold Plating Rectifier

Brand Name:	Xingtongli
Model Number:	GKD12-1000CVC
MOQ:	1pcs
Price:	980-1200$/unit
Packaging Details:	strong plywood standard exporting package
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE ISO9001

Supply Ability:

200 Set/Sets per Month

Product Description

The 12V 1000A 400V 3-Phase Remote-Controlled IGBT Electroplating Rectifier is an industrial-grade power supply designed for high-precision metal plating and surface treatment. It supports a 3-phase 400V input and 0-12V/0-1000A DC output, integrated with remote control functionality (RS485/Modbus protocol) to adapt to automated production lines. Utilizing IGBT high-frequency inverter technology and a nanocrystalline soft magnetic transformer, it ensures efficient and stable power supply (efficiency ≥94%) with output ripple ≤1%, guaranteeing uniform and dense coatings for metals like nickel, copper, silver, and gold.

Product Parameters

Input Specifications

Input Voltage: 3-Phase AC 400V
Frequency: 50/60Hz
Input Wiring: 3-phase

Output Specifications

Voltage Range: 0-12V continuously adjustable
Current Range: 0-1000A continuous output
Output Modes: Automatic CC/CV switching with soft start to prevent inrush current
Output Ripple: ≤1%
Efficiency: ≥89%

Protection System

Overcurrent Protection
Overheat Protection
Input Protection
Output Protection

Mechanical and Environmental Parameters

Cooling Method: Forced air cooling (standard silent fan with intelligent speed control)/ water cooling (optional, requires external circulation system)
Operating Temperature: -10°C~+45°
Protection Rating: IP54 (dustproof and water spray resistant, suitable for humid/dusty industrial environments)
Installation Method: Cabinet floor mounting/ rack mounting (optional rail brackets)

Certifications and Compliance

Safety Certifications: CE certification (LVD Low Voltage Directive + EMC Electromagnetic Compatibility Directive), RoHS 2.0 lead-free certification
Industry Standards: Compliant with GB/T 3859.1-2013 Semiconductor Converters and ISO 9001 quality management system
